Rated Voltage |
115V | 230V |
Part Number |
5011400A |
5011401A |
Cooling Capacity |
16,000 BTU/h |
|
Heating Capacity |
16,200 BTU/h |
|
Rated Frequency |
60Hz |
50 / 60Hz |
Rated Current |
11.2 A |
5.7 / 5.6A |
Refrigerant Charge |
R410A (0.7kg) |
|
Comp. LRA |
60A |
35A |
Min. Condenser Water Flow |
3.43 Gal/Min. (13 L/Min.) |
|
Dimensions (L x W x H) |
(L x W x H) 24.3 x 13.5 x 13 in (619 x 343 x 330 mm) |
|
Weight |
88 lbs (40kg) |
FCF Platinum | Product Features
- Long and slim new footprint featured on the 12,000 and 16,000 BTU/h models – allowing for easy replacement of existing units
- Engineered for better performance with a higher BTU/h rating across a variety of ambient scenarios
- Digital display with controller and cable come standard
- 2-year warranty with unmatched product reliability
- Marine-grade stainless steel frame for durability and longevity
- Cupronickel evaporator
- Proprietary compressor – well balanced and quiet than ever before
- Low cost replacement parts
Accessories | KoolAir Pumps & Control
Webasto is the North American exclusive distributor of KoolAir Pumps to the marine industry.
- Three pumps available; PM500, PM1000 and TPM1000
- PM500 is a FULLY submersible pump
- Run Dry and Thermal Overload Protection
- All are available in 115 and 230V
- Motors are rated as: continuous duty
- One phase pumps
